AE403V Aerator

AE403V Aerator

AE401 Drum Series

This mechanical 19" / 48cm wide aerator eliminates cumbersome filling of a conventional centre drum found on other units on the market, which are prone to wear, vibration and damage.

Billy Goat's outboard drive wheels also eliminate centre wheel slip and abuse from ramp loading with the tines engaged. Instead of bulky steel weights, water weight is positioned directly over the tines for better aeration depth.

Operators love the softest drive and tine engagement and the exclusive Lift N Lock™ feature allows the tines to be raised by simply lifting up on the handle.

The Fold-n-Go™ handles and the tilt up serviceability make service and transport convenient and simple.

This AE403V model is powered by a reliable Vanguard® engine and can aerate up to 2.000m2 per hour.

Features

Outboard Drive Wheels

Eliminate both center wheel slip and abuse from ramp loading with the tines engaged.

Single Bolt Tine Fastener

Rock solid and easy to service.

Tine Engagement and Lift N Lock™ Disengagement

For best in class comfort and productivity.

Easy to Store and Service

Tilt up serviceability plus Fold-n-Go™ handles are excellent for transport and storage and fold without tools.

Water Tank

Proprietary water tank eliminates bulky side weights. 23 litre capacity.

Specifications

Only 2 products can be compared at once. Please remove one of your selections to compare this product.

Only 3 products can be compared at once. Please remove one of your selections to compare this product.

At least one product must be displayed. Please select another option to remove this product

Engine Make
Vanguard
Performance kW*
3,7
Performance HP*
5,0
Displacement (cc)
169
Productivity (m2/h)
2000
Working Width (cm/in)
48 / 19
Tine Type
Drum
Tine Depth (cm)
8,9
Number of Tines
24
Tine pattern (cm)
12 x 18
Drive Type
Self Propelled
Transmission Type
Geared
Gears Forward
1.0
Wheel Type
Semi-Pneumatic
Weight (kg)
114
Length (cm)
145
Width (cm)
74
Height (cm)
133

* All power levels are provided by Briggs & Stratton.

Accessories

Solid Steel Tines

Excellent for improving drainage or for other no-plug applications. Sold as a set. (360394-S)
